Fagor CNC 8055 TC - Travel Limits

Self-teaching manual
10
·TC· Option
THEORY ON CNC MACHINES.
1
1.4 Travel limits.
This type of machines have two types of travel limits:
• Physical limits. They are set by the machine to prevent the carriages from going off its ways (cams and mechanical stops).
• CNC limits. They are set by the manufacturer at the CNC to prevent the carriages from running into the physical travel limits.
Physical limits.
CNC limits.
Machine reference.
