Fagor CNC 8055 TC User Manual

Self-teaching manual
12
·TC· Option
THEORY ON CNC MACHINES.
1
1.6 Work units.
A X=0 Z=0 X=0 Z=0
B X=12 Z=-12 X=24 Z=-12
C X=12 Z=-42 X=24 Z=-42
D X=22 Z=-52 X=44 Z=-52
Programming units.
The units are set by the manufacturer and may be
in mm or inches.
Programming units.
The units are set by the manufacturer and may be
in radius or diameter.
Feedrate of the axes.
The units are set by the manufacturer and may be:
millimeters (inches) per minute:
The feedrate is independent from the spindle
speed.
millimeters (inches) per turn:
The feedrate changes with the spindle speed.
Millimeters.
Inches.
Radius. Diameters.
It is recommended to work at constant surface
speed (CSS) and feedrate in millimeters/turn.
This will lengthen tool life and will improve the part
finish.
