DTC1000/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.2)
70
Using the Magnetic Encoding Tab – Custom Encoding or Raw Binary
Encoding Mode
Window TAB Procedure Procedure (continued)
Select No Parity to change the
Character Parity to none.
Select Even Parity to change
the Character Parity to Even
Parity.
Select Odd Parity to change
the Character Parity to Odd
Parity. (Note: This is the
default for all tracks.)
Reverse Bit Order is used to
reverse the character bits and is
used for the encryption of data
in specific programs
Add Leading Zeros is used to
add a set number of leading
zeros to the magnetic string in
order to move the starting
point of the encoded data in
specific programs for
encryption of data.
Reviewing the ISO Track Locations
The magnetic Encoding Module encodes onto tracks in accordance with an ISO 7811-2 Magnetic Stripe.
For track locations, review the display below.
TRACK1 0.110"
TRACK2 0.110"
TRACK3 0.110"
0.130"
0.140"
0.223" 0.353" 0.493"

Fargo DTC1000 Specifications

General

Product color	Black, Silver
Internal memory	32 MB
Built-in barcodes	-
Total input capacity	100 sheets
Maximum resolution	300 x 300 DPI
Print speed (color)	120 card/h
Print speed (monochrome)	515 card/h
Compatible operating systems	- Windows XP / Vista (32 bit & 64 bit) / Server 2003 & 2008 / Windows 7 / - Linux
Bundled software	Swift D Embedded Badging Application, ARGO Workbench Diagnosis Utility
Interface	USB
Optional connectivity	Ethernet

Weight and Dimensions

Weight	3400 g
Dimensions (WxDxH)	475 x 234 x 249 mm
