DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 116
Step
Procedure
8
The printhead assembly can now be pulled up and out from the frame.
9
The back side of Printhead assembly shown has been removed from the printer.
