Fargo DTC4250e - Remove;Replace Flipper Feed Roller, Pinch Roller, Gears

DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 81
.
Remove/Replace the Flipper Feed Roller (D930149), Pinch Roller D920013 & F000338)
Pinch Roller Gears (D30165 & D930166)
Step
Procedure
1
Caution: Turn OFF the Printer and unplug the power cord from the Printer.
2
Start with the instruction for replacing the Flipper Table.
D930149
D920013 + F000338
D930165 (3 used) D930166
Tools needed: T10 Torx screwdriver
Estimated Repair Time: 20 minutes
Preparation: Remove the Covers
Important: This procedure can only be performed by
authorized service personnel.
