Fargo DTC4250e - DTC1250 e DUAL - DTC4250 e Single Printer Cover Removal

DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 14
.
DTC1250e DUAL - DTC4250e Single Printer Cover Removal
(NOTE: Use this procedure for removing the covers of the DTC1250e DUAL & DTC4250e printer cover
AFTER the Dual-Sided Printing Module has been removed.)
DTC1250e DUAL
DTC4250e Single
Tools needed: T10 Torx screwdriver
Estimated Repair Time: 15 minutes
Preparation:
Important: This procedure can only be performed by
authorized service personnel.
DTC1250e DUAL DTC4250e
Top Cover D930181-03 D930181-01
Front Door D930183-03 D930183-04
Output Cover N/A D930281-01
Display Cover –blank D930189-03 D930189-01
Display Cover/PCB MDP-00059 MDP-00093
Output Bin D930333
100 Card Input D930022 D930022
