Fargo DTC4250e - Page 17

DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 17
.
Step
Procedure
6
Remove the Input Hopper by tilting back and away from the frame. There are tabs at the bottom that
hold the hopper to the frame.
7
Remove the screw that holds the Output Cover in place.
8
Tilt down and remove the Output Cover.
