Fargo DTC4250e User Manual

DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 4
.
Appendix C ............................................................................................................................................... 127
Lamination Module Mainboard connections ............................................................................................................... 127
Upper Sensing Cables ........................................................................................................................................... 127
Feed & Lower Sensing Cables .............................................................................................................................. 128
Upper Lam Head Cables ........................................................................................................................................ 129
Lower Lam Head Cables ........................................................................................................................................ 130
Lower Motor Cables ............................................................................................................................................... 131
Upper RFID and Ribbon Cable .............................................................................................................................. 132
Appendix D ............................................................................................................................................... 133
Engineering Drawings ............................................................................................................................................ 133

Fargo DTC4250e Specifications

General

Print Method	Dye-sublimation / resin thermal transfer
Resolution	300 dpi
Memory	32 MB RAM
Print Speed	Up to 225 cards per hour (YMCKO)
Card Capacity	100 cards input, 100 cards output
Card Sizes	CR-80 (85.6mm x 54mm)
Card Thickness	0.009" - 0.040" / 0.229mm - 1.016mm
Connectivity	USB 2.0, Ethernet
Operating Systems	Windows 7, 8, 10
Dimensions	9.8"H x 18.1"W x 9.2"D
Power Requirements	100-240 VAC, 50/60 Hz
