Fargo DTC4250e - Page 63

DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 63
.
Step
Procedure
3
Remove the Damper Cap (F000487)
Use a thin flathead screwdriver to loosen one side.
The cap will pop off.
NOTE: Replace the Damper Cap by lining up the shaft first then snap the Damper Cap back on.
Verify the gray shaft is pushed up to hold the encoder wheel in place.
