Positioneachlatchsothatthebottomofthe
latchgoesoverthelipedgeonthescanner.
%
Closethelatchesbypressingthelatchtabs
inward.Thelatchesshouldlockeasily.If
theydon'tlockeasily,checkthemounting
brackettoensurethatitisplacedproperlyon
topofthescanner.

CAUTION: Ensurethatthemounting
bracketissecurelyattached
beforeyouattempttomove
thescanner.
&
Poweronthecamera,andproceedwith
applicationsetupandcalibration.
  

FARO
®
FOCUS® Laser Scanner Accessories Manual
Chapter 5: PanoCam
FARO FOCUS® LASER SCANNER (00.00) Page24of36
