Faro FOCUS - Removing the Panocam Mount from the Scanner


RemovingthePanoCamMountFromtheScanner
!
PoweroffthecameraandtheFOCUSscanner.

"
Undothelatchesandrotatethemsotheyarefreefrom
thelipedgesonthescanner.

#
 Rotatethecamera/mountassemblyupwardabout45
degrees,andthenpulltheassemblyawayfromthe
scanner.
$
Usethehexkeytoloosenthecamerascrew.
%
Removethecamera,beingcarefulnottodamagethe
USB-Cconnectors.

&
Storethecameraandmountsafely.Toprotectthe
cameraandthelenses,usethesoftcoverincludedwith
yourpanoramiccamera.

  


