Fastjet A400 Series User Manual

●
When Tri gger Mode select Tr ig ger. Once triggered the printer will
print Continuous Time, unless the photocell level condition.
When Trigg er Mode select Gate. Only meet photocell level
condition, the printer will print after triggered.
● Select Continuous Mode Open option.
● Do not need to set.
●
Set the Internal Interval to use the pluses internally created to set
the distance between each print.
●
Set the External Interval to use the external shaft encoder pulses to
set the distance between each print. Set the External Interval , if
external shaft encoder connected.
c. Photocell Level menus.
Figure2- 25. Photocell Level Signal Block menus.
● Set Photocell Levels high or low to allow the high or low
activating photocells.
● Blocking Time set to avoid twice triggered for one product.
Note
Selected Manual Print to trigger print, if there is no photocell. Set the
Tri gg er Level the save to Photocell 1 Level in Photocell Level.
 32
