Fastjet A400 Series - Ink Line Adjustment

3.5 Ink Line Adjustment
" Left/Right adjustment
Loose the 1 screw in the screen and move the “2” slightly can move
the ink line left or right.
" Up/Down adjustment
Loose the 1 screw in the screen and move the “2” slightly can move
the ink line up and down.
Note
Before adjust the ink line, please confirm the nozzle is unblock, standard
ink line position reference to ink line observation.
 42
