Maintenance - Lubricants and symbols
4812163801.pdf2019-04-30
Maintenance - Lubricants and symbols
Always use high-quality lubricants and the
amounts recommended. Too much grease or
oil can cause overheating, resulting in rapid
wear.
Always use high-quality lubricants and the
amounts recommended. Too much grease or
oil can cause overheating, resulting in rapid
wear.
Fluid volumesFluid volumes
Rear axle (Limited Slip)Rear axle (Limited Slip)
- Differential 11 liters 11.6 qts- Differential 11 liters 11.6 qts
- Planetary gear 2 liters/side 2.1 qts/side- Planetary gear 2 liters/side 2.1 qts/side
Rear axle (No-Spin)Rear axle (No-Spin)
- Differential 12,5 liters 13.2 qts- Differential 12,5 liters 13.2 qts
- Planetary gear 1,9 liters/side 2.0 qts/side- Planetary gear 1,9 liters/side 2.0 qts/side
DrumDrum
- Drum gear 3.5 liters 3.7 qts- Drum gear 3.5 liters 3.7 qts
- Drum cartridge 2,2 liters/side 2.3 qts/side- Drum cartridge 2,2 liters/side 2.3 qts/side
Hydraulic reservoir 41 liters 10.8 galHydraulic reservoir 41 liters 10.8 gal
Oil in hydraulic systemOil in hydraulic system
CA4600 80 liters 21.1 galCA4600 80 liters 21.1 gal
CA5000. CA5500, CA6000,
CA6500
84 liters 22.2 galCA5000. CA5500, CA6000,
CA6500
84 liters 22.2 gal
Diesel engineDiesel engine
- Lubricating oil (incl. filter
replacement)
12.5 liters 13.2 qts- Lubricating oil (incl. filter
replacement)
12.5 liters 13.2 qts
- Coolant, without cab 27.2 liters 28.8 qts- Coolant, without cab 27.2 liters 28.8 qts
- Coolant, with cab 29.6 liters 31.3 qts- Coolant, with cab 29.6 liters 31.3 qts
Other fuel and lubricants are required when
operating in areas with extremely high or
extremely low ambient temperatures. See the
‘Special instructions’ chapter, or consult
Dynapac.
Other fuel and lubricants are required when
operating in areas with extremely high or
extremely low ambient temperatures. See the
‘Special instructions’ chapter, or consult
Dynapac.
ENGINE OIL Air temperature -15°C - +50°C
(5°F-122°F)
Dynapac Engine 300 P/N 4812161859 (5 liters),
P/N 4812161860 (20 liters)
ENGINE OIL Air temperature -15°C - +50°C
(5°F-122°F)
Dynapac Engine 300 P/N 4812161859 (5 liters),
P/N 4812161860 (20 liters)
HYDRAULIC FLUID Air temperature -15°C - +50°C
(5°F-122°F)
Dynapac Hydraulic 300 P/N 4812151868 (20 litres),
P/N 4812161869 (209 liters)
HYDRAULIC FLUID Air temperature -15°C - +50°C
(5°F-122°F)
Dynapac Hydraulic 300 P/N 4812151868 (20 litres),
P/N 4812161869 (209 liters)
Ambient air temperature above
+40°C (104°F)
Shell Tellus S2 V100Ambient air temperature above
+40°C (104°F)
Shell Tellus S2 V100
103
