Fayat Group DYNAPAC CA6000 - Dimensions, Top View

Technical specifications
4812163801.pdf2019-04-30
Dimensions, top view
Dimensions mm inDimensions mm in
B1 Width, standard equipped rollerB1 Width, standard equipped roller
CA4600 2304 91CA4600 2304 91
CA5000, CA5500, CA6000 2340 92CA5000, CA5500, CA6000 2340 92
CA6500 2380 94CA6500 2380 94
B2 Width, tractor section 2130 84B2 Width, tractor section 2130 84
O1 Overhang, left frame sideO1 Overhang, left frame side
CA4600 87 3.4CA4600 87 3.4
CA5000, CA5500, CA6000 105 4.1CA5000, CA5500, CA6000 105 4.1
CA6500 125 4.9CA6500 125 4.9
O2 Overhang, right frame sideO2 Overhang, right frame side
CA4600 87 3.4CA4600 87 3.4
CA5000, CA5500, CA6000 105 4.1CA5000, CA5500, CA6000 105 4.1
CA6500 125 4.9CA6500 125 4.9
R1 Turn radius, externalR1 Turn radius, external
CA4600 5600 220CA4600 5600 220
CA5000, CA5500, CA6000, CA6500 5800 228CA5000, CA5500, CA6000, CA6500 5800 228
R2 Turning radius, innerR2 Turning radius, inner
CA4600 3380 133CA4600 3380 133
CA5000, CA5500, CA6000, CA6500 3300 130CA5000, CA5500, CA6000, CA6500 3300 130
W Width, drum 2130 84W Width, drum 2130 84
