Operation
4812163801.pdf2019-04-30
2
3
Fig. Control panel
1. TC (Anti-spin)
2. Forward/Reverse lever
3. Potentiometer (speed limiter)
1
Machine with TC (Anti-Spin)
TC (Anti-Spin) (1) is activated by default (LED lit).
Position the speed control (3) in suitable position.
TC (Anti-Spin) activated/disengaged is shown in the
center of the speedometer.
Fig. The display shows whether TC
(Anti-Spin) is activated or disengaged
Carefully move the forward/reverse lever (2) forwards
or backwards, depending on which direction of travel
is required.
Speed increases as the lever is moved away from the
neutral position.
Slopes (TC (Anti-Spin))
To optimize available pulling force and protect the
machine's engine against over-revving while working
or during transport driving on steep slopes (>10%),
you must select low setting on the speed limiter
(potentiometer).
Never drive with a higher gear/at a faster speed that
the machine requires to climb up the same slope!
77
