Chapter 4 SPECIFICATIONS
4.1 General Specifications
Table 4.1 summarizes the general specifications of the multi-function keypad TP-G1-CLS / TP-G1-ELS.
Table 4.1 General Specifications
Item Specifications Remarks
Enclosure Front side: IP40; Rear side: IP20
Environment Indoor only.
Shall be free from corrosive gases, flammable gases, dust, and
direct sunlight.
Ambient temperature (during operation) -10 to +50°C
Ambient humidity 5 to 95% RH (no condensation)
Altitude 1000 m or below
Vibration 3 mm (max.) : 2 - 9 Hz
9.8 m/s
2
: 9 - 20 Hz
2 m/s
2
: 20 - 55 Hz
1 m/s
2
: 55 - 200 Hz
Ambient temperature (during storage) -25 to +65°C
Ambient humidity (during storage) 5 to 95% RH (no condensation)
External dimensions See the figure below.
Mass 129 g
 External dimensions
(Unit: mm)
Model name
4-1
