Chapter 1 BEFORE USING THE MULTI-FUNCTION KEYPAD
1.1 Acceptance Inspection
Unpack the package and check the following:
(1) The package contains a multi-function keypad and the
following attached goods.
Attached goods
Multi-function keypad fixing screws
Instruction manual (this book)
(2) There have been no problems during transportation. In
particular, no parts are damaged or have fallen out of place
nor are there any dents on the body.
(3) The model name "TP-G1-CLS" or "TP-G1-ELS" is printed on
the back of the multi-function keypad as shown in Figure 1.1.
The language that can be displayed is different in each model
name.(Refer to the table below)
Model name Language that can be displayed
TP-G1-CLS Chinese, English, Japanese
TP-G1-ELS
English, Japanese, German, French
Spanish, Italian
If you suspect the product is not working properly or if you have
any questions about your product, contact your Fuji Electric
representative.
Figure 1.1 Back of Multi-function Keypad
TP-G1-CLS / TP-G1-ELS
1.2 Inverters with which the Multi-function Keypad Interfaces
The multi-function keypad interfaces with the following Fuji inverters:
Series Type of inverter
*
Remarks
FRENIC-Lift FRN
LM1S-2
FRN
LM1S-4
(Each
has its meaning as shown below,
represented by an alphanumeric character.)
No restriction is there for use of this product.
* Type of inverter
For the details of the Inverter type identification, refer to the FRENIC-Lift Instruction Manual
(INR-SI47-1038-E), Chapter 1, Section 1.1 "Acceptance Inspection."
1-1
