Chapter 3 OPERATION USING THE MULTI-FUNCTION KEYPAD
3.1 Components on the Keypad
The keypad allows you to start and stop the motor, view various data including maintenance information and
alarm information, set function codes, monitor I/O signal status, copy data, and calculate the load factor.
7-segment
LED monitor
Program key
Indicator indexes
DOWN key
Stop key
UP key
Function/Data key
Run forward key
Run reverse key
Reset key
Shift key
Remote/Local
key
LED indicator
LCD monitor
3-1
