FEASA LED ANALYSER

ICT VERSION

External Capture Mode

“SETEXTERNALOUTPUTCCTI”: CCT, Duv and intensity are reported for all the fibres

automatically after an external trigger has been applied:

01 ccccc +0.dddd iiiii

02 ccccc +0.dddd iiiii

…

20 ccccc +0.dddd iiiii

“SETEXTERNALOUTPUTWI”: Dominant Wavelength and Intensity are reported for all the fibres

automatically after an external trigger has been applied:

01 www iiiii

02 www iiiii

…

20 www iiiii

The command “GETEXTERNALOUTPUT” returns the report mode selected.
