Feasa ICT Series User Manual

FEASA LED ANALYSER
ICT VERSION
Capture Sequence Mode
Set/Put SequenceChannel@@ - Select sequence mode Fiber No.
Transmit Receive
setsequencechannel@@
putsequencechannel@@
OK
OK
Where:
@@ represents the Fiber and is a number in the range 01 -20.
Description
This command is used to set the Fiber number associated with the Capture Sequence
command. The command putSequencemode1 should be executed before this command.
In addition, the commands putsequencecapture, putsequencewait and
putsequencenumber should be issued before this command.
The Analyser can store up to 8000 captures in memory when this mode is selected.
putsequencechannel commands are stored in RAM memory while setsequencechannel
commands are stored in Flash memory.
Example:
The PC transmits putsequencechannel04 to the LED Analyser to instruct it to do sequence
capture on Fiber 04 only. The LED Analyser will return a string OK to the PC.
putsequencechannel04
OK
To determine which Fiber Number is set, use the command getsequencechannel. It will
return a number in the range 01 to 20.
getsequencechannel
05 (Fiber Number 5)
Back to Index
112
