FEASA LED ANALYSER

ICT VERSION

Capture Sequence Mode

ResetSequenceAll - Reset all sequence patterns

Transmit Receive

resetsequenceall OK

Where:

all represents the all sequence patterns stores in the Analyser. (max 21 patterns)

Description

This command resets all sequence pattern numbers. Up to 21 patterns can be stored.

All sequence patterns will be deleted from memory.

Example:

The PC transmits resetsequenceall to the LED Analyser to instruct it to delete all sequence

patterns.

resetsequenceall
