Feasa ICT Series User Manual

FEASA LED ANALYSER
ICT VERSION
Synchronous Serial Mode
Read RGB and Intensity (RGBI)
This command will instruct the LED Analyser to output the RGB colour and Intensity of a LED.
All the LED data should have been previously captured.
The code for this command is 0x30 – this must be transmitted to the LED Analyser followed by
the Fiber Number of the LED to be tested. The Fiber Number is a hexadecimal number in the
range 0x01 – 0x14 (in decimal this represents numbers 1 -20). The Analyser will return 6
bytes of data – 1 byte each for Red, Green, Blue and 3 bytes for Intensity.
Command Data Transmitted Data Received
Read RGB + Intensity 0x30 + fiber num
(1byte)
R(1byte)+G(1byte)+B(1byte) +
Int(3byte)
Red = (byte1)
Green = (byte2)
Blue = (byte3)
The Intensity value is output in the last 3 bytes with the most significant byte first.
To convert the Intensity data to a decimal number use the formula:-
Intensity = (byte4 * 65536) + (byte5 * 256) + byte6
Note:- The data output in all the bytes are hexadecimal numbers.
Back to Index
47
