Chapter 6 Description of Operations
PAGE 6-57
D-No. 004 Judgment Item 2 Standard setting: 000001
*****1: Timeout Check Only the change 0 ￫ 1 is enabled.
･ Whether or not the fastening time from the start of fastening to D-No. 105 [1st Torque] or D-No.
205 [1st Angle] or from D-No. 105 [1st Torque] or D-No. 205 [1st Angle] to the end of fastening is
within the high and low limit ranges is judged respectively.
****1*: Revolution Check
･ Whether or not the number of rundown revolutions from the start to end of fastening is within the
high and low limit ranges is judged.
***1**: Differential Angle Check
･ Whether or not the differential angle, calculated from the rate 2 from D-No.114 [Rate 2 Start
Torque] to D-No. 115 [Rate 2 End Torque] and the final torque, is within the high and low limit
ranges is judged.
**1***: Snug Torque Check
･ Whether or not the torque value is within the high limit range is judged when D-No. 107 [Snug
Torque] is detected.
*1****: Break Away Torque Check
･ Whether or not the torque value is within the high limit range is judged during reverse operation.
1*****: Torque Inhibit Check
･ Whether or not the torque value is within the high limit range is judged during operation at D-No.
205 [Torque Inhibit Angle].
