FEC HFC3000 - Performance

Chapter 2 Specifications
PAGE 2-3
2-2 Performance
2-2-1 Fastening Performance
Torque precision
From 1/2 ~ Calibration torque
3σ/:
X
5% or less
From 1/4 ~ 1/2 Calibration torque
3σ/
X
: 6% or less
(Precisions in case of in-house standard fastening.
*May differ according to work.)
Angle display minimm unit
0.1 degree
Angle internal control unit
0.1 degree
Torque transducer accuracy
±1% of full scale
Torque transducer linearity
±0.5% of full scale
Fastening method
Torque method/Angle method
Torque rate setting
3
List of Tools Refer to Appendix.
MODEL
MAXIMUM
TORQUE
[Nm]
MAXIMUM
ROTATION
SPEED
[rpm]
MINIMUM
ROTATION
SPEED
[rpm]
HFT-015M50-A1
15.00
1215
1
HFT-025M80-A1
25.00
1070
1
HFT-060M80-A
60.0
446
1
HFT-080M80-A
80.0
330
1
HFT-130M80-A
130.0
203
1
HFT-015M80-S1
15.00
1600
1
HFT-040M80-A1
40.00
648
1
HFT-040M80-S
40.00
694
1
HFT-015M50-P1
15.00
1190
1
HFT-035M80-P1
35.00
5.00
778
1
2-2-2 controller
CPU: 32-bit RISC
Data communication: Ethernet: 1 port RS232C: 1 port
Fieldbus D-NET, P-BUS, CC-Link, etc. (optional)
Monitor functions: Torque, angle pulse, current
