Chapter 4 Installation
PAGE 4-5
4-4 Tool Cable Specifications
■Tool Cable (Cable type: FEB-1616-M**)
■Tool Cable (Cable type: C15-F7-M**)
Tool Side
Controller side
Tool Side
Controller Side
(AWG16-4/AWG24-24)
(#22 shell-19)
Total length L
Total length L
