Chapter 6 Description of Operations
PAGE 6-59
D-No.006 Interrupt Operation During Fastening Standard setting: 000000
*****1: Pulse Fastening Operation
・Set this to ON if fastening by pulsing is to be performed (pulsing is started after detection of 1ST).
****1*: Gyro Setup Enable
・With a P type or T type tool, the pause operation functions are enabled when this is set to ON.
***1**: Angle Head Torque Variation Monitor
・With an angle head tool, the torque variation is monitored when this is set to ON.
**1***: Reverse Between 1-2 Step
・If this is set to ON and there is a 1ST stop, a reverse operation is performed before restarting (① in the
diagram below).
*1****: Reverse Between 2-3 Step
・If this is set to ON and there is a 2ND stop, a reverse operation is performed before restarting (② in the
diagram below).
To Next Page
