Chapter 9 External Interface
PAGE 9-9
●EDS File
An EDS file is an information file related to the communication specifications of EtherNet/IP-compatible
device and a separate, individual file exists for each device. The EDS file is necessary for using the
EtherNet/IP configuration software to connect the MFC-EN and the PLC.
The EDS file is included in the installation CD for the HFC3000 User Console. Please refer to the
instruction manual for the EtherNet/IP configuration software concerning the appropriate method for using the
EDS file.
●Module Pin Configuration
No.
Signal
Description
1
TD+
Send data +
2
TD-
Send data -
3
RD+
Receive data +
4
-
Not used
5
-
Not used
6
RD-
Receive data -
7
-
Not used
8
-
Not used
* The cable is not included with the equipment. Please prepare a LAN cable of Category 5e or higher on your
own.
・Be sure to connect the cable with all power turned OFF.
