TECHNICAL DATA
VZL-S/ Ko 12.01 print no. 2664C
Maintenance schedule
Farmer 307, 308, 309
As of vehicle no. 117 .. 5001, 118 .. 5001, 119 .. 5001
Maintenance jobs during and after the running-in period and for the workshop after the 5th Service
No.
Services
regularly 1)
daily
Job Schedule
See also Operating Manual
Care and Maintenance
General notes and technical data, types of fluid and oil
Correct levels are determined by dipstick check or from the overflow at the
inspection hole.
Observe all accident prevention regulations and comply with directives for
handling and disposing of fluid and lubricants.
1.
50
2.
250
3.
500
4.
750
5.
1000
annu
al or
every
500
every 2
years
or
2000
operating hours
1 Engine
X Check oil level. The difference between the Min. and Max. markings on the dipstick is approx. 4.0
litres.
After 100 operating hours add oil to the Max. marking on the dipstick.
Wait until level is just above the Min. marking, do not fill above Max. marking.
X X X X Replace engine oil and filter cartridge 2). Oil quantity: 11.0 l.
Type of oil: Year-round SHPD engine oils in accordance with ACEA
E3-96 or year-round engine oils in accordance with
API-CD, ACEA E2-96 or ACEA E3-96
X 1,500 Check valve clearance, adjust if necessary
(service intervention).
Valve clearance:
check and adjust if
necessary
Intake valve 0.3 mm, exhaust valve 0.5 mm, engine cold
(max. 50
°C).
Note: In the event of a faulty engine, you can also check the injection nozzles.
X annu-
ally
Replace fuel filter unit. Repeat more often if engine shows loss of efficiency.
X X X X Check V-belt, retighten if necessary 1). Operating tension 400+50 N (40+5 kp)
X X X X X Check coolant level, top up if necessary. Coolant level: With cold engine, fill to between the Min. and Max. mar-
kings on the expansion tank, if necessary top up with clean
lime-free water containing correct proportion of antifreeze.
X Replace coolant, screw radiator cap back on. Coolant quantity: 13 l
A concentration of 35 - 50 vol.-% antifreeze and anti-corrosive is necessary
throughout the year, even in frost-free areas.
Antifreeze solution as specified in Fendt list of Fluids and Lubricants 4).
In the Tropics - use only corrosion inhibitors as specified in Fendt list of Fluids and
Lubricants 4).
as requi-
red
Check, and if necessary, clean cooling fins of
engine, hydraulics, intercooler, gearbox and air
conditioning.
Blow out with compressed air or use a vacuum cleaner.
