32
OPERATION
10.4 Front PTO
Text-module
(optional)
PTO protective sleeve (A)
Operation_Pic_number:1
Season selector
Operation_Pic_number:1
Turn off the engine.
Engage or disengage season selector with lever
(A).
Rotation direction of the front PTO = clockwise,
looked at in travel direction, refer to sticker.
Danger:
After operating front PTO,
disengage season selector and
replace the protective sleeve on the
PTO stub shaft.
Fig.42
Fig.43
10.5 Activating front PTO
Operation_Pic_number:1
The front PTO can be engaged or disengaged
using control lever (A) while travelling.
Note:
Engage the PTO at as slow an engine speed
as possible.
Operation_Pic_number:1
● Turn rotary switch (A) to the "Front PTO"
symbol.
The digital display indicates the front PTO rpm.
Danger:
Before engaging the PTO, make sure
no-one remains in the hazard zone.
Never engage the PTO when the
engine is not running.
Fig.44
Fig.45
