MOD MC PREMIUM PM
2.1 LIST OF COMPONENTS
2 2.1.3 ACCESSORIES
SHEET METAL
PANEL
ACCESSORIES PER PANEL
A
85 mm REGULATION
SUPPORT
B
M10
DIN 6923
C
RECTANGULAR
WASHER
D
M10 x 25
DIN 6334
x2
700 ≤ PL ≤ 1.150 x2
1.200 ≤ PL ≤ 1.400 x3
700 ≤ PL ≤ 1.150 x2
1.200 ≤ PL ≤ 1.400 x3
700 ≤ PL ≤ 1.150 x4
1.200 ≤ PL ≤ 1.400 x6
700 ≤ PL ≤ 1.150 x2
1.200 ≤ PL ≤ 1.400 x3
E
8 mm
GUIDE SHOE
F
M8 x 20
DIN 603
G
M8
DIN 934
x2
x2
x2
H
SEPARATOR
I
ANTITURN
x2
x2
J
15 mm
GUIDE SHOE
K
WASHER M8
L
M8 X 16
DIN 933
M
M8
NF-E25-511 M
x2
x2
x2
x2
N
0,8 mm SHIM
THICKNESS
O
0,5 mm SHIM
THICKNESS
x2
x4
