3.2 ASSEMBLY INSTRUCTIONS
3
3.2.8.4 COUPLING LATERAL VIEW
3.2.8.4.1
Once the car door has been assembled the following must be checked: The gap between the panels and the
car entrance, the gap between panels and sill and finally the overlaps between skate and landing locking
device.
AIM
