MOD MC PREMIUM PM
15 15
AIM
ALUMINIUM 15 mm
TRACK
REINFORCED ALUMINIUM
15 mm TRACK
STEEL MASSIVE
5
5
5
ALUMINIUM 8 mm
RECESS TRACK
REINFORCED ALUMINIUM
8 mm RECESS TRACK
5
5
5
3.2.4.2.2
For correct regulation please ensure the shown points are fulfilled.
