86
MOD MC PREMIUM PM
D
+
-
+
-
B
C
AIM
3.2.7.2
Once the vertical reinforcements have been assembled
follow as shown below.
ACCESSORIES PER SET
B M6 DIN 6923 x2
D
M6 x 5 DIN 966
x2
C M6 x 15 Bolt x2
DELIVERED SETS
B
700 ≤ PL ≤ 1.400 x1
C 700 ≤ PL ≤ 1.400 x1
D
700 ≤ PL ≤ 850 x2
900 ≤ PL ≤ 1.100 x3
1.200 ≤ PL ≤ 1.400 x4
3.2 ASSEMBLY INSTRUCTIONS
3
3.2.7 TOE GUARD INSTALLATION
