Fermax IP-Fermax IPF-00 - Technical Parametres; Electrical Parametres; Mechanical Dimensions

IP VarioBell - installation and operating instructions
74
Technical parametres
Electrical parametres
Parametr
Value
conditions
Interface
Ethernet 10BaseT, 100BaseTx
VoIP protocol
SIP 2.0 defined RFC3261
Default IP address
192.168.1.250
Audio
G.711u, G.711a, G.726-32b, GSM, G722,
G729 (optional)
Band range
300Hz – 3400 Hz
Echo supression
Automatical
Output power
Class D, 1W/8ohm, 94dB/1kHz/1m/1%
Video
série JPEG, MJPG, stream H.263, H.264
Resolution
Max. 640 x 480
Camera angle
120deg H x 110deg. V
Power supply - adapter
12VDC ± 2V , 12VAC ± 1V
- or PoE
IEEE802.3af Altern. A + B
Max. consumption
300mA
12Vss
Max. switching voltage by
relays
48V
when I < 1A
Max. switching current by relays
2A
when U < 30 V
Temperature range
- 20 to + 80°C
Mechanical dimensions
