Festo CECC-X-M1-... 2017-09a English
10
7 Status LEDs
The product is equipped with the following status LEDs è Fig. 1 9:
Status LED
Meaning Status LED Meaning
Run Application status Net Device detected
Error Error Mod Reserved
Fig. 3
8 Power supplies
Note
Use an external overload protection for the power supply
of the device.
Pay attention to the required current consumption.
8.1 Power supply [X1]
for device, digital/analogue inputs
and motor controller direct connection (logic)
Residual current for all supplied ports: 750 mA
of which intrinsic current consumption: 200 mA
Terminal Port Comments
X1.1 24 U+ power supply
X1.2 0 U– load
X1.3 Functional earth
X1.4 – Not connected
Fig. 4
