Festo CECC-X-M1 series User Manual

Festo CECC-X-M1-... 2017-09a English
9
6.1 Mounting on H-rail
1. Insert the product into the H-rail.
2. Press the product in the direction of the arrow until it audibly engages.
6.2 Dismounting from H-rail
1. Remove the plug connector on the underside of the product.
2. Unlock the product via the clip è Fig. 2aI.
Use a suitable tool, e.g. a screwdriver.
3. Remove the product from the H-rail.
6.3 Mounting onto mounting surface
Note
Damage to the product caused by mounting on uneven or flexible
surfaces.
 Only mount the product on an even, torsionally rigid surface.
1. Drill two mounting holes bJ in the mounting surface (4.5 mm,
spacing è Fig. 2 – hole pattern).
2. Secure the product in place with two M4 screws.
– Screw head diameter: 7 mm
– Max. tightening torque: 0.8 Nm
6.4 Dismounting from mounting surface
1. Loosen two M4 screws.
2. Remove the product from the mounting surface.
Additional information regarding installation and commissioning
can be found in the Festo Support Portal è www.festo.com/sp.
