Festo CECC-X-M1-... 2017-09a English
11
8.2 Power supply [X5]
for digital outputs
Residual current for all supplied ports: 5 A
Terminal Port Comments
X5.1 24 U+ power supply
X5.2 0 U– load
Fig. 5
8.3 Load voltage supply [X21]
for motor controller
Residual current for all supplied ports: 8 A
Terminal Comments
X21.1 24 V/48 V load voltage supply feed
X21.2 GND
Fig. 6
Note
Damage to the product in case of overload.
If there is a load on all digital outputs of 0.5 A each, the residual cur
rent can be exceeded as soon as additional consuming devices are
used.
Consider all current loads.
For special configurations, contact the local Festo service.
