Festo CECC-X-M1-... 2017-09a English
12
8.4 Load voltage supply [X11]
for IO-Link
This port is used for the power supply of an IO-Link device that is con
nected via the IO-Link master port.
Current consumption for IO-Link: 0.75 A
Note
Damage to the product in the event of a mix-up of the connecting pins.
When establishing the load voltage supply for the IO-Link master
port, make sure that only connecting pins X11.1 and X11.2 are
used.
Terminal
Port Comments Internal
connection
X11.1 24 UA+ Infeed for IO-Link master port X15.4
X11.2 0 UA– Infeed for IO-Link master port X15.5
Fig. 7
8.5 Power supply [X11]
for encoder
Encoder current consumption: 0.3 A
Termi
nal
Port Comments
X11.3 UG Encoder power supply (ground)
X11.4 UE Encoder power supply (5 V)
Fig. 8
