7. Preparations for commissioning
106 Festo P.BE-CMMS-AS-HW-EN en 0708NH
7. Preparations for commissioning
7.1 General connection instructions
As the routing of the connecting cables is critical for EMC, it is es-
sential that you follow the previous Chapter 227H6.5.5 228HEMC-compliant
wiring (Seite 229H103)!
Warning
DANGER!
Failure to follow the instructions in Chapter 230H2 231HSafety instructions for
electrical drives and controllers (page 232H11) can result in property
damage, bodily injury, electrical shock or, in extreme cases, death.
7.2 Tools / material
Tool
- Screwdriver size 1
- Serial interface cable
- Incremental encoder cable
- Motor cable
- Power supply cable
- Control cable
7.3 Connecting the motor
Connecting the mo-
tor
1. Insert the motor cable plug in the corresponding socket on the
motor and secure it.
2. Insert the PHOENIX plug into the socket [X6] on the device.
3. Clamp the cable shields to the shield terminals (not suitable as
strain-relief).
4. Insert the motor cable plug in the corresponding socket on the
motor and secure it.
5. Insert the D-sub plug in socket [X2] of the device and secure the
locking screws.
6. Check all plug connectors once again.
