A. Technical specifications
116 Festo P.BE-CMMS-AS-HW-EN en 0708NH
Sensors
Values
Table A.4 Technical data: Motor temperature monitoring
A.2 Operation and display components
The CMMS-AS motor controller has two LEDs on the front and one seven-segment display
for showing the operating status.
Component
Function
Seven-segment display
Displays the operating mode and an error code
should an error occur
Ready LED (green)
Ready status
BUS LED (yellow)
CAN bus status display
Table A.5 Display elements
A.2.1 Status display
Ready Green LED
CAN bus active Yellow LED
Status display Seven-segment display blue
The following status information is shown on the seven-segment display (see Chapter
8.2.1):
End stage enabled (bar)
Motor turning speed control operating mode (segment rotation)
Positioning operation display P with alternating record number
Error with number (flashing error number, three-position)
A.2.2 Control elements
The node number can be set via DIP switches on the front of the device:
7x node number
1x load firmware from SD card
2x baud rate
1X CAN on / off
1x terminating resistor
