6. Electrical installation
Festo P.BE-CMMS-AS-HW-EN en 0708NH 91
1 Main switch
2 Fuse
3 Power pack for
control voltage
4 CMMS-AS
5 PC
6 EMMS-AS
Fig. 6.4 Complete structure of CMMS-AS with motor and PC
6
1
2
3
4
5
