2. Commissioning
2-8
Festo P.BE-CP-FB13-E-EN en 0112e
76543210
Bit
Bit
Long data
00 = 1 byte/word
...
15 = 16 bytes/wor ds
Input/output
00 = Specific identifier formats*
)
01 = Input
10 = output
11 = Input/output
Length
0 = byte
1=word
Consistency
0 = byte or word
1 = complete length
*) Is not supported
Fig. 2/2: Composition of the identifier byte
Example:
00010000
b
= 016
d
(010
h
): 8DI = 8 digital inputs
