2. Commissioning
2-9
Festo P.BE-CP-FB13-E-EN en 0112e
Standard mode
In standard mode configure 16 outputs and 16 inputs per as-
signed string. DP identifier: 049 or 16DX for each assigned
string.
The following table provides a summary of the possible entries
for the valve terminal in standard mode.
Last used
string number
Number of
inputs/outputs
Individual identifier
0 2 16DX
1 4 16DX, 16DX
2 6 16DX, 16DX, 16DX
3 8 16DX, 16DX, 16DX, 16DX
Fig. 2/3: Standard mode: Possible configuration of the
inputs and outputs
The last used string is decisive for the number of DP ident-
ifiers, even if numerically lower strings are not assigned (see
manual “CP system, installation and commissioning ”).
Example:
CP system with 3 strings, a total of 3 input and 3 output mod-
ules, highest assigned string number = 2.
DP identifier Comment
0 16DX Input module and output module of
string 0
1 16DX Input module and output module of
string 1
2 16DX Input module and output module of
string 2
Fig. 2/4: Configuration in standard mode
