2. Commissioning
2−27
Festo P.BE−CPX−FB11−EN en 0503b
Assign the slave to a scanner
1. Double−click the desired scanner in the network.
A dialogue box will open.
2. Select the Scanlist" register and assign the existing
slaves to the scanner.
1
1
Button for assigning the slave
Fig.2/6: Scanlist" register (example)
