2. Commissioning
2−17
Festo P.BE−CPX−FB38−EN en 0804NH
Module
no.
Module Input address Output address
0 Bus node CPX−FB38  
1 Digital 8−input module CPX−8DE I32 Ū I39 
2 Digital 4−output module CPX−4DA  O128 Ū O135
*)
3 CP interface CPX−CP...
(In this case: 4 bytes I, 16 bytes O)
I0 Ū I32 O0 Ū O127
4 Digital multi−I/O module CPX−8DE−8DA I40 Ū I47 O136 Ū O143
5 MPA1 pneumatic module (8 O)  O144 Ū O151
6 MPA1 pneumatic module (8 O)  O152 Ū O159
*)
8 bits occupied, 4 bits used
Tab.2/10: Addressing the example terminal 2 (see Fig.2/2)
Example 3: CPX terminal with analogue module and
VTSApneumatics
Fig.2/3 shows as an example a CPX terminal with analogue
module and VSTA pneumatics as well as the following setting:
 Status bits activated
 VTSA pneumatic interface set to 1 Ū 8 valve coils (8 O)
The address assignment for
this example terminal
(inFig.2/3) is shown in Tab.2/11.
