Getting Started with Festo MecLab
Stack Magazine Station
Step 3: Simulate the pneumatic circuit diagram
Start the simulation by clicking on the “Start” button.
Left-clicking on the left or right manual override will extend or retract the cylinder.
Figure 4.13: Simulating the pneumatic circuit diagram
