Getting Started with Festo MecLab
Conveyor Station
Table 5.2: Important components in FluidSIM®
Symbol Designation Function
Multi-pin plug distribu-
tor
Establishes the con-
nection with the
Hardware. Labels
must match between
this device and the la-
bels on the actuators
and
sensors in the Fluid-
SIM® program.
Digital module (can
also be used as a PLC)
Contains the logic pro-
gram. Double click on
the device to open.
Voltage supply and 0
volts return
Supplies components
with power.
Attention: Without
power the components
will not work in the
simulation.
0V Q1 Q2 Q3 Q4 Q5 Q6
24V I1 I2 I3 I4 I5 I6
0
2
4
6
8
10
1
3
5
7
9
11
Priority active
0V
+
24V
