Getting Started with Festo MecLab
Conveyor Station
Table 5.2: Important components in FluidSIM®
Symbol
Designation
Function
Motor, DC Drives the conveyor.
Switched on and off
using relays.
Switch For manual interven-
tion in the program.
Sensor (optical) The connections on
the top and bottom are
for the power supply.
The connection on
the side is the signal
output.
Relay coil with switch
When current flows
through the coil, the
associated switch (the
switch with the same
label) will either close
or open.
M
34
3
4
A1
A2
