2. Fitting
2−4
Festo P.BE−MTR−DCI−IO−EN en 0606b
2.2 Dimensions of the motor unit
H0 H2
H1
B1
B2
D1
D2
D3
D4
L1
L2
L3
L4
L5
5
13
T1
Sizes [mm] 32 42 52 62
Gear ratio G7/G14 G7 G14 G7 G14 G7/G14/G22
Diameter of
flange/shaft
D D1
D2
D3
D4


21.5 h8
6h7
42 g10
42 ±0.1
25 h8
8h7
52 g10
52 ±0.1
32 h8
12 h7
62 g10
62 ±0.1
40 j7
14 h7
Height H H0
H1
H2
65.3 ±0.4
21.6 ±0.15
41.5 ±0.3
70,8 ±0,4
26,5 ±0,6
54,5 ±0,4
94.8 ±0.4
37 ±0,9
76.5 ±0.4
128 ±0.5
60.8 ±0.35
128 ±0.5
Length L L1
L2
L3
L4
175.5 ±1

18.7 ±0.6
2.5 ±0.3
176 ±1
33.3 ±1
25 ±1
2 ±0.2
176 ±1
46,3 ±1
25 ±1
2 ±0.2
194 ±1
39 ±1
33 ±1
3 ±0.3
194 ±1
53 ±1
33 ±1
3 ±0,3
270 ±1
47 ±1
39 ±1
5 ±0.3
Width B B1
B2
33.8 ±0.3
46.3 ±0.4
44.8 ±0.4
53.3 ±0.4
63.8 ±0.4
69.5 ±0.4
105.1 ±0.4
105.1 ±0.4
Depth T T1 6 10 10 10
Tab.2/1: Dimensions of the motor unit
